Brand: For Trimble
Trimble 66694 Cable Replacement
5 products sold in last 15 hours
Selling fast! 1 person has in their cart
The Trimble 66694 Cable is a power cable designed to connect the battery or CAN bus cable to Trimble’s FMX-1000 (also known as FM-1000) display.
30 in stock
21 people are viewing this right now
- Estimated Delivery : Up to 15 business days
- Express Shipping & Returns : On all orders over $200
Overview
This replacement power cable provides a robust 4‑pin Deutsch DT connection between a vehicle’s battery or CAN harness and an agriculture-grade display. At six feet (≈1.8 m) in length and built with 14 AWG conductors, it ensures reliable power delivery and durability in harsh field conditions.
Key Features
- Connector Type: 4‑pin Deutsch DT plug and receptacle for secure, vibration‑resistant mating.
- Cable Length: 6 ft (≈1.8 m) for flexible routing in various installation setups.
- Wire Gauge: 14 AWG tinned copper conductors minimize voltage drop and resist corrosion.
- Construction: Over‑molded PVC jacket with integrated strain relief; resists oil, UV, and abrasion.
Specifications
| Attribute | Details |
|---|---|
| Part Number | 66694 |
| Connector | 4‑pin Deutsch DT (female ↔ male) |
| Length | 6 ft (≈1.8 m) |
| Wire Gauge | 14 AWG |
| Application | Power feed to vehicle‑mounted display via Port 1 |
Installation & Maintenance
- Routing: Secure cable away from moving parts, sharp edges, and high‑heat areas; use cable ties every 12–18 inches.
- Mating: Ensure the Deutsch shell “clicks” fully to confirm engagement; partial seating can cause intermittent power loss.
- Inspection: Periodically check the PVC jacket for cuts, abrasions, and verify strain‑relief integrity at both ends.
- Grounding: If used in a CAN bus network, ground any shield per the implement’s wiring diagram.
Best Practices
- Use cables built to original 14 AWG Deutsch DT specifications to maintain performance.
- Verify pin‑out color coding before installation to prevent miswiring.
- Consult a qualified technician if unfamiliar with vehicle electrical systems.
| Weight | 0.2 kg |
|---|---|
| Dimensions | 18 × 12 × 10 cm |
